Haier pharmacy refrigerators (Model: HYC-85GD / HYC-85FD, 85L/3cf) are cutting-edge counter-top/under-counter medical refrigerators designed to meet the highest standards in vaccine storage and preservation. Equipped with advanced cooling technology and precision temperature control, it ensures optimal conditions for storing vaccines, with a temperature uniformity of +/-0.7°C.
Warranty: 3-Year Parts and Labor; 5-Year on Compressor Parts
Download Brochure [pdf]
Key Features
|
Medical Grade Refrigerator: |
|
Excellent performance: temperature uniformity ≤ 1°C |
|
Low energy consumption: 0.99 kWh/day |
|
Intelligent anti-condensation: |
|
Eco-friendly hydrocarbon refrigerant (R290) and CFC-free polyurethane insulation for reduced global warming |
|
Self-closing door with magnetic gasket for positive seal. |
Specifications
| Technical Data | |
| Model |
HYC-85GD (Glass Door) HYC-85FD (Solid Door) |
| Cabinet Type | Table-top / Under-counter |
| Climate Class | N (16°C ~ 32°C) |
| Cooling Type | Forced air circulation |
| Defrost Mode | Auto defrost |
| Refrigerant | R600a |
| Sound Level (dB(A)) | 35 |
| Performance | |
| Temperature Range (°C) | 2 ~ 8 |
| Control | |
| Controller | Microprocessor |
| Display | Digital |
| Electrical Data | |
| Power Supply (V/Hz) | 115 / 60 |
| Power (W) | 90 |
| Electrical Current (A) | 1.2 |
| Power Consumption (kWh/day) | 0.99 |
| Dimensions | |
| Capacity (L/Cu.Ft) | 85 / 3.0 |
| Net/Gross Weight (approx) |
36 ~ 41 kg (79.4 ~ 90.4 lbs) |
| Interior Dimension (WxDxH) | 15.9 in x 15.9 in x 21.9 in |
| Exterior Dimension (WxDxH) | 19.5 in x 21.7 in x 29.1in |
| Packing Dimension (WxDxH) | 22.4 in x 24.8 in x 31.9 in |
| Alarms | |
| High/Low Temperature | Yes |
| Door Ajar | Yes |
| Power Failure | Yes |
| Low Battery | Yes |
| Sensor Error | Yes |
| Communication Failure | Yes |
| Remote Alarm | Yes |
| Accessories | |
| Roller | 2 |
| Foot | 2 |
| Porthole | 1 |
| Shelves/Baskets | 2/1 |
| Printer | N/A |
| USB Interface | Optional |
| RS485 | Optional |
| Others | |
| Certification | EC (coming soon) |
